Nippon Labs 14AWG Power Cord, Black NEMA 5-15P to C19, SJT 15A 125V

A 14 AWG cord from a North American NEMA 5-15P wall plug to an IEC 60320 C19 connector, rated 15A at 125V. The C19 is the large, square-shouldered connector used on equipment that draws more than a C13 is meant to carry — blade chassis, large UPS units, high-density PDUs and some enterprise switches.

14/3 UL SJT 105°C BLACK COLOR NEMA 5-15P TO IEC-60320-C19

• This heavy duty NEMA 5-15P to C19 power cord is designed for server applications that require a higher-rated cable.
• Connect devices like computers and servers to a PDU in a data center.
• This heavy duty 14 AWG power cord is fully molded for durability.
• UL and cUL listed.
• All relevant materials are complied with RoHS and REACH directive.

What it's for

• Feeding a rack UPS or PDU with a C20 inlet directly from a wall outlet.
• Powering servers and blade chassis whose inlet is a C20 rather than a C14.
• Lab and broadcast equipment specified with a C20 inlet.
• Replacing an OEM C19 cord that is the wrong length for the rack.

Good to know

C19 and C20 — what is the difference?
C19 is the connector on the cord; C20 is the inlet on the equipment. They mate with each other. C19 will not fit a C14 inlet, and a C13 will not fit a C20 — the two families are deliberately not interchangeable.

Why is a C19 cord bigger?
The C19/C20 pairing is rated for higher current than C13/C14, so the contacts and the conductors are larger. That is the whole point of the connector: it signals, physically, that this device needs a heavier feed.

What does 14 AWG mean here?
AWG is conductor thickness, and the scale runs backwards — a lower number is a thicker wire. At 14 AWG this cord is built to carry its rated 15A at 125V without the conductors heating up. A thinner cord with a higher AWG number carries less current.

What is a SJT jacket?
SJT is a thermoplastic-jacketed, hard-service cord — the heavier, more abrasion-resistant jacket used on equipment and rack cords.

How much load can I actually put on it?
The cord is rated 15A at 125V. The usual engineering practice is to keep a continuous load at or below 80% of a circuit or cord rating and leave headroom for inrush when equipment powers on, so size the cord to the equipment rather than to the outlet.
